Big Coverage Area 2000 CBM HVAC Industrial Scent Diffuser for Fairs
Introduction of Industrial Scent Diffuser
CH122 industrial scent diffuser is working with the advanced cold air diffusion technology; the essential oil or other oil-based oil will be changed into the dry scent mist, this procedure is without any heating so that it could well protect the benefit of the essential oil. And these dry scent mist become the dry mist so that there will be no trace no residue in the air.
The powerful air pump inside make CH122 could covers from 1000 to 2000 cubic meters areas such as hotels, 4S shops, Bars, Shopping Malls, KTV, Banks, Brand Stores, Night Clubs, Restaurant, Air Ports, Subways, Salons, Approach, Cruise Lines, Casinos, Healthcare Facilities, Homes, Apartments, Hospitals, Pet Care Facilities, Retail Venues, Senior Living, Spas and homes and more indoor diffusion.
The inner fan could direct blows the dry scent mist to make it much more evenly and more fast to reach every corner of the rooms.
The body material is metal and it is very durable. Classic black and white 2 colors are available.
It has the locked protection, only the keys could open the door of the machine. So that no one could take away the oil bottle or touch the program.
Technical Data
| Model No. | CH122 |
| Shell Material | Durable Metal |
| Color | White , Black |
| Dimension | W240 by D150 by H370mm |
| Net Weight | 5.5 KG |
| Standard Packing | 6 pieces per one master carton |
| Power Supply | DC12V 14W |
| Coverage | from1000 to 2000 cubic meters |
| Installation Way | Connect to HVAC system, Wall Mounted or Stand-alone |
| Cartridge | 1000ml Aluminum Oil Bottle |
| Essential Oil Consumption | From 0.2ml to 3.8 ml per hour |
| Noise Level | Less than 42dba |
| Warranty | 1 Year |
| Country of Origin | Made In China |
| Application | Hotels, Office Building, Lobby, Cinemas and more. |
| Function | Air Freshener |
| Type | Cold air diffusion |
Usefulness
The CH122 scent machine is to use as the stand-alone or wall mounted type, it is perfect to connect to HVAC system so that the dry nanoparticle scent mist could be delivered to every areas which are connected by the HVAC system. It could not only uses for industry scent marketing, but also could use for homes. The good smelling could remove the bad odor.
Accessory
| 1000ml Empty Oil Bottle | 1 piece | User Manual | 1 piece |
| Screws and Connector | 4 sets | Keys | 2 pieces |
| Spare Atomizing Core | 1 piece | AC Power Adapter | 1 piece |
| Air Tube | 1 piece | Air Tube Connector | 1 piece |
Product Maintenance
In the below cases, please do the maintenance same as our instruction.
| Case 1 | If don't use for a long time, please clean the machine after final use. |
| Case 2 | Every one- two months clean one time. |
| Case 3 | Before change to another flavor of the essential oil |
| Cleaning steps | 1, Put the 95% alcohol into the empty bottle, |
| 2, Set the strongest intensity, turn on the machine to work for 10-15 minutes, |
| 3, Turn off it and finally pour away the alcohol. |
